Optical fiber induction direct vibration feeding： The front sleeve vibrating tray uses direct vibration for feeding. The optical fiber senses whether there is a product. When fully loaded, it stops immediately. It is accurate and efficient and avoids material waste. |
|
|
CCD visual recognition： Accurately identify whether there is a wire break in the front sleeve, and accurately determine the angular direction of the front sleeve and the mandrel. After automatic orientation selection, insert the mandrel. It has high precision and consistency. |
|
|
High-precision mandrel automatic wire turning： The processing precision of the mandrel is as high as 0.005. It stably supports the wire turning operation with zero-error precise positioning. It accurately controls the angle, position and force. The wire turning is uniform and the angles are consistent. The mandrel is mirror-polished to prevent wire breakage and scratching. |
|
|
Precise four-point crimping： High-precision fixture locks the position accuracy of the rear sleeve. The fixture rotates stably. The servo motor performs four-point crimping. The fixtures are few but refined to ensure accurate and error-free crimping of products. |
|
Dimension:1660*1200*1800mm Capacity:15~20 pcs/min Power:1000W Air Pressure/Voltage:0.4-0.6Mpa/220VAC Product diameter that can be produced:0.4, 0.6, 0.635, 0.8, 1.0; 1.5, 2.0, 2.4. 0.4 drawn strip with outer step; 0.9F with inner step |
|
