Machine Name :
Desktop hyperboloid socket rear sleeve crimping machine
Machine Details:
Desktop Hyperboloid Socket Rear Sleeve Crimping Machine is a non-standard automation equipment designed for precision connector assembly. With dimensions of 610×750×380mm, 3000W power, and production efficiency of 15-20 pcs/min, it operates at 0.5-0.8Mpa air pressure and 220V AC voltage. Key advantages include fiber optic induction feeding system for precise material control, CCD vision recognition for front sleeve inspection, high-precision automatic wire turning with zero positioning error, and servo-driven four-point crimping ensuring exceptional consistency. The modular design adapts to various hyperboloid socket crimping requirements.
Function Highlights:
1. Fiber optic induction direct shock feeding:Vibration plate direct shock feeding, fiber optic induction products, full material stop precise and efficient, avoid waste of materials
2. CCD Vision recognition:Accurately identify whether the front sleeve has broken wires, precisely identify the Angle of the front sleeve and automatically sort the direction.
3. High precision automatic turning:High-precision stable threading, uniform threading,consistent angles, no scratches or broken thread sand precise positioning with zero error.
4. Precise four-point crimping:The four-point crimping of the servo motor ensures strong consistency.
Machine Configuration:
Machine Size：610*750*380mm
Machine Efficiency：15-20pcs/min
Machine Power：3000w
Air Pressure/Voltage: 0.5-0.8Mpa/220V AC
